THE NERDY DETAILS
- 4mm thick 304 Series Stainless Mounting bracket| which includes rubber dampener and an additional 3mm upper plate.
- A360.0 Cast Housing | Boasting superior strength and corrosion resistance.
- 3mm Thick GE Lexan Lens with hard coating | Virtually unbreakable & scratch resistant
- 100% Polyester UV and abrasion resistant powder coat
- IP68 | Dust & Particle tight + Water-proof up to 3 meters
- Nitto Denko Pressure Equalization vent with membrane | Protects against water ingress| dust and contaminants.
- Environmentally Sealed Deutsch DT-2 connector
- EMI RFI Suppression circuitry - We guarantee it.
- Each 7" TYPE-X Sport comprises 32 of OSRAM's OSLON LEDs| selected for its high luminous flux and perfectly matches optical properties.
- 4 wide-beam reflectors built-in| which form a lateral shaped flood pattern designed to minimize valuable light wasted up to the sky.
- 5700K CCT offers stunning clarity and definition with excellent Colour Rendering Index (CRI)
TECH SPECS
LED | 32 x Osram Oslon SSL |
RAW LUMENS | 16|640 (Pair) |
TESTED LUMENS | 12|820 (Pair) |
AMP DRAW | 6.4A @ 13.2v (each) |
POWER DRAW | 85W (each) |
CANDELA | 819|200cd |
BEAM PATTERN | 4 x Spread 28 x Spot Beam |
INGRESS PROTECTION | IP68 | Submersible up to 3m |
COLOUR TEMP (CCT) | 5700K |
VOLTAGE COMPATIBILITY | 12v & 24v |
LUMEN MAINTENANCE | 50|000 LM-80 |
WEIGHT | 2.250kg (each) |
OPERATING TEMP | -40°C - 60°C |
PHOTOMETRIC DATA | |
10 m | 8|129 L |
50 m | 327 Lx |
200 m | 20 Lx |
300 m | 9 Lx |
400 m | 5 Lx |
895 m | 1Lx |
SKU | LEDTYPE-X-SRT-7INCH |
Brand | STEDI |
Shipping Weight | 0.5000kg |
Shipping Width | 0.200m |
Shipping Height | 0.250m |
Shipping Length | 0.200m |
