Clearview Power Slide - XL PS-XL
SKU code: PS-XL
Low Power Consumption
Power consumption is critical in any set up and the Power Slide’s low current draw makes it suitable for most existing battery setups.
When empty| the smallest Power Slide draws a max current of around 4.0 Amps during lowering| and 5.2 Amps during lifting. When loaded with 80kg| it draws a max current of 4.0Amps during lowering and 13.0 Amps during lifting. The largest Power Slide draws 3.1 Amps and 4.1 Amps respectively when empty and 3.1 Amps and 11.0 Amps respectively when loaded with 100kgs.
Lightweight Efficiency
A large| fully stocked fridge can be extremely heavy| requiring a Power Slide that can effectively function under its weight| without adding unnecessary additional weight to the overall set-up.
Weight/GVM is an important factor in any set-up and even the largest Power Slide weighs only 38kg (only 29kg for the smallest Power Slide)!
With a load rating of 180kg| the lightweight Clearview Power Slide™ is designed to smoothly lower and raise a fully loaded fridge. Its unique scissor lift design is supported on each side by synchronized| self-aligning actuators| ensuring that the fridge always remains perfectly level. Great for those of us who don’t like our cans and bottles pre-shaken!
How it works:
Simply unlock the travel lock mechanism| pull down on the yellow ergonomic slide quick-release runner levers and pull the fridge towards you to full extension.
Now the magic happens! Lower and raise your fridge with the press of a button for convenient access to its contents.
- Tri Scissor Synchro-Lift Technology allows the fridge platform to be lifted and lowered exactly vertically| simultaneously by two actuators. This balanced power generated by a set of synchronized| self-aligning actuators ensures that the fridge always remains perfectly level.
- Quick release double runners and heavy duty Travel Lock that is guaranteed not to rattle!
- Innovative design with no exposed cables and 15-amp Anderson Plug power supply as standard
- 180Kg load rating to support a fully loaded fridge or pantry
- Smoothly lowers the fridge up to 290mm
- The PS-XL is engineered to suit most large fridges including and up to the ARB 96L| DOMETIC & WAECO 95L| MYCOOLMAN 85L| 96L| 105L| EvaKool| Giant 80L| Kickass 95L| Kings 75L| and Rydge Rider 72L.
- Easy Operation and Installation with self-aligning Actuators
- Gently lowers with the press of a button| allowing you to access your fridge
- Fits most Large Fridges on the market
- Easy Operation and Installation
- Tri Scissor Synchro-Lift Technology
- Lightweight| aluminium extruded construction
- The new Clearview Power Slide™ is lighter than any other fridge lowering slide
- A much smaller mounting BASE then the Easy Slide™ width and length in comparable sizing
- Heavy Duty Travel Locks
- Designed to hold 180kgs
- 140mm extended travel
- Powdercoated finish
- Maximum drop of 290mm
- Tested to outlast 10|000 movements
- Embossed Rubber Mat to support Fridge
- Fridge Straps included (4)
- 3 Year manufacturer warranty
- SAFER| SMOOTHER & SILENT!!
TRAY
960 (L) X 560 (W)
BASE
1041 (L) X 714 (W)
TRAVEL
1181MM
WEIGHT
38KG
LOAD RATING
180KG
Please note that these parts are built to order and may take 1-2 weeks to arrive at our Rutherford warehouse. For a more accurate lead time for a product| please contact us directly.
| SKU | PS-XL |
| Barcode # | 740781868795 |
| Brand | Clearview |
| Shipping Weight | 49.0000kg |
| Shipping Width | 1.160m |
| Shipping Height | 0.280m |
| Shipping Length | 0.820m |
