THE BEAM PATTERN

If you’re looking for a driving light that offers near-field spread| keep moving| this is not that. The optical properties of the hooded reflector design is best described as high-beam on steroids. The ST-X excels in the high-speed| high-way application when mid to long-range visibility is critical.



  • Significantly minimises adverse reflection from road signs
  • Controlled vertical spread minimises reflections off of high-mounted road signs.

KEY FEATURES

  • 8x 15W LEDs
  • LED Parking / Position Light Function (Amber or White built-in)
  • Breather allows pressure equalisation when rapid heat up and cool down cycles occur
  • Anodized Polyester Powder Coat
  • Weatherproof Deutsch® DTP Connector
  • Includes adjustable Side brackets & Sliding bottom brackets
  • Includes our Easy-Fit Plug & Play High Beam Wiring Harness with HB3 & H4 adapter (Compatible with both negative and positive switched vehicles)
  • Protected against reverse polarity
  • Shockproof| IP68 waterproof| UV Shielded
  • Protected Against RFI / EMC Interference
  • Voltage & current surge protection
  • Pulse Width Modulation Thermal Management

Lux Chart Max Power



VOLTAGE 9-36V
AMPERES 8.5A @ 12V (full power), 3.46A @ 12V (limit power).
POWER 102W (full power). 41.52W (limit power)
LUMENS 4010LM (full power). 2310LM (limit power)
COLOUR TEMPERATURE 5000K
AMP RATING 0.3a
PHOTOMETRIC DATA 1 lux @ 586m (full power), 1 lux @ 445m (limit power)
LENS MATERIAL Optical grade, Hard-Coated LEXAN
HOUSING MATERIAL 6063 EXTRUSION
INGRESS PROTECTION IP68
CANDELAS 344017 (full power), 189429 (limit power)
CONNECTOR 60cm Cable with DTP 4in
OPERATING TEMP -40°C ~ +60°C
CERTIFICATES R112, ref. 50 and R10
LIFESPAN 50, 000hrs (LM80)
PRODUCT WEIGHT 2.6kg
SHIPPING WEIGHT 3.1kg
SKU LEDST-X-20-8L
Brand STEDI
Shipping Weight 4.3000kg
Shipping Width 0.300m
Shipping Height 0.250m
Shipping Length 0.600m
